What Power Tools Do Carpenters Use

Carpentry is a skilled trade and a craft in which the primary work performed is cutting, shaping and installation of building materials during construction of buildings, ships, timber bridges and concrete framework. The term includes both structural timberwork in framing and items such as doors, windows, and staircases.

A carpenter’s work may also extend to interior jobs, requiring some of the skills of a joiner. These jobs include making door frames, cabinets, countertops, staircases and assorted moulding and trim. Much of the skill involves joining wood inconspicuously for the sake of appearance, as opposed to the joining of unseen structural pieces.

Carpenters use a variety of tools, both hand and power tools, in construction, design and completion of their task. In this article, power tools used for carpentry will be the focus of discussion.

Power Tools used for Carpentry:

Miter/Mitre Saw

A power miter/mitre saw is a power tool used to make a quick, accurate crosscut in a work piece at a selected angle. It is commonly used for cutting of a mould and trimming. Most of these saws are relatively small and portable, with common blade sizes ranging from eight to twelve inches.

Characteristics

• Making regular board cuts

• Angled Mitre/Miter cuts
• Compound angle cuts
• Trim work

Circular Saw

A circular saw is a hand held type device that uses a toothed abrasive disc or blade to cut wood using a rotary motion spinning around an arbor. Circular saw blades are specifically designed for each particular material they are intended to cut. They are designed for making rip-cuts, cross-cuts or combination of both rip and cross cuts. Circular saws can be powered by electricity, gasoline engines or a hydraulic motor which allows it to be fastened to heavy equipment, eliminating the need for a separate energy source.

Circular saws can be either left handed or right handed depending on the side of the blade where the motor sits.

Characteristics

• Cutting is done by teeth on the edge of a metal blade or by an abrasive wheel
• Cuts done are straight and reasonably accurate.

Jigsaw

This is a type of powered saw consisting of a motor that drives a narrow blade in a rapid up and down motion. The blade of the jigsaw usually cuts on the upstroke as a result of its teeth pointing upwards. If a clean cut is important, the workpiece should be turned in order for the material to prevent splintering on the front. Jigsaws are primarily used to make curved, intricate cuts in woods.

Characteristics

• Straight Cut
• Plunge Cut
• Bevel Cut

Corded Jigsaws are connected to a continuous power supply and have an unlimited run time. Also, they can be used for heavy duty cuts and are lighter than the cordless jigsaw. However, it is limited by the length of the cord.

Cordless jigsaws are portable and flexible provided their batteries are charged. However, the power may drain quickly when cutting thick wood, requiring regular charging, they are heavier and more expensive than corded jigsaws.

Table Saw

This consists of a circular saw blade, mounted on an arbor, which is driven by an electric motor while the blade protrudes above the top of the table. It is worth knowing that the depth of the cut is varied by moving the blade up and down: The higher the blade protrudes above the table, the deeper the cut that is made in the material. The angle of cut is controlled by adjusting the angle of the blade.

Table saws are dangerous tools because the operator holds the material being cut rather than the saw. This feature makes it dangerous as the user can accidentally move hands into the spinning blade.

Characteristics

• Automatic Braking – If the saw detects a change in current, an automatic braking system is activated, forcing an aluminium brake block into the blade while retracting the blades.
• Flash Detection Sensor – This is a sensor that immediately disengages a table saw if it detects human flesh by sending a signal to activate an aluminium brake.

Impact Driver

An impact driver is a power tool that delivers a strong, sudden rotational force used to tighten or loosen (drive) screws and nuts. They can also be described as high-torque tools primarily used for driving screws and tightening nuts. This is due to the torque available, one will typically be able to quickly drive long, wide screws into the toughest of materials.

Characteristics

• ¼-inch hex bit holder which grips small screwdriver bits
• Lighter and Smaller when compared to Drill Drivers
• Performs tasks quicker

Drill Driver

A drill driver works on the same principle as an impact driver. However, it is slower and has less power than an impact driver. It also has benefits such as being equipped with a clutch that disengages the drill’s drivetrain when the tool reaches a specified amount of torque. By disengaging the drivetrain at that point, it prevents stripping the fastener head, snapping the fastener off or driving the fastener right through a piece of material.

Contact GZ Industrial Supplies Nigeria today to purchase yours.

Frequently Asked Questions

Q1 How can I maintain and prolong the life of my power tools?

Regularly clean and lubricate your tools, store them in a dry and secure place, replace worn-out parts, and follow maintenance recommendations in the user manual.

Q2 Do power tools use a lot of electricity?

Small power tools, such as jigsaws and sanders, usually require 2 to 8 amps of current. Generally, 6 to 16 amps are needed for bigger power tools (such as routers, circular saws, table saws, lathes, etc.). Certain instruments, including air compressors and duct collectors, could require considerably more power.

Q3 Do power tools use hydraulics?

Construction and heavy industry use hydraulic power tools for tough tasks. When compared to comparable-sized air or electric power tools, these tools have a significantly higher force and torque density.
